Description
- Each circuit for max. 20 luminaires
- Single luminaire monitoring
- Switching of individual luminaires or groups of luminaires via switching inputs
NRG+ SUB B24
NRG + Sub for sub-distribution areas and system extensions.
230V AC/DC outgoing circuits with integrated monitoring and maintained and non-maintained functions.
Designed according to BS EN 50171, BS EN 62034.
Additional information
| Weight | 16 kg |
|---|---|
| Dimensions (D x W x H) | 140 × 324 × 674 mm |
| System | NRG+ |
| Insulation class | I |
| Compliance | CE, UKCA |
| IP rating | IP40 |
| Mounting system | Surface wall |
| Nominal input voltage (V) | 1~N/PE 230 V 50 Hz |
| Nominal output voltage (V) | 230 VAC / 216 VDC ± 15 % |
| Outgoing circuits | 24 x 3 A 690 W |
| Colour | RAL 9016 |
| Material | Galvanised and painted metal sheet |
| Operating temperature (°C) | 0 to +40 |
