Safety IP65-rated wall luminaire is suitable for indoor and outdoor use.
Its robust, oval design has an IK10 rating and provides high-performance illumination.
The luminaire is equipped with 3 x 5 W power LED.
Exilux’s fully automatic self-testing NRG BUS or NRG ZB system complies with BS EN 62034 and is incorporated into all emergency lighting models.
It meets the requirements of the relevant harmonised European standards and BS EN 60598-1 and BS EN 60598-2-22.
| Weight | 1.2 kg |
|---|---|
| Nominal input voltage (V) | 230 V 50/60 Hz |
| System | NRG BUS DALI 2 |
| Insulation class | I |
| Compliance | CE, UKCA |
| IP rating | IP65 |
| IK rating | IK10 |
| EN 1838 | EN 1838 |
| Glow wire test | 960 °C – 30s |
| Mounting luminaire | Surface wall |
| Warranty | 5 Years, 10 Years |
| Environments | Cold |
| Emergency duration (h) | 3 |
| Battery | LiFePO4 6.4 V 3.2 Ah |
| Nominal flux (lm) | 620 |
| Polar curve image | YES |
| Power consumption AC (W) | Max. 11 |
| Charging times (h) | 24 |
| Colour temperature (°K) | 4000 |
| Service life L80B20 | 50000 |
| Material | DIE-CAST ALUMINIUM – PC |
| Colour | RAL 9017 |
| Operating temperature (°C) | -30 to +45 |
