WAYLUX IP65 RC NRG ZB W/E 3H Safety Luminaire

System NRG ZB Wireless
Insulation class II
Compliance CE
Compliance UKCA
IP rating IP65
IK rating IK04
EN 1838 EN 1838
Glow wire test 850 °C - 30s
Mounting luminaire Recessed ceiling
Warranty 5 Years
Warranty 10 Years

Safety IP65 luminaire designed for recessed ceiling mounting with high lumen output.

Part No. L21026 Categories: , Tag:

Description

Automotive-grade CSP LEDs with a rotating system for dual lenses, designed for use in escape routes and wide areas.
Quick-connect terminal blocks make installation easy.
Luminaire is equipped with 2 x 3 W power LED.
Exilux’s fully automatic self-testing NRG BUS or NRG ZB system complies with BS EN 62034 and is incorporated into all emergency lighting models.
It meets the requirements of the relevant harmonised European standards and BS EN 60598-1 and BS EN 60598-2-22.

Wireless Features

  • Type: Wireless MESH network
  • Operating frequency: 2.4 GHz
  • Max power: 10 mW
  • Compliant to RED Directive 2014/53/EU
  • Compliant to European standards: EN 300 328, EN 301 489-1, EN 301 489-3

Additional information

Weight 0.52 kg
Nominal input voltage (V)

230 V 50/60 Hz

System

NRG ZB Wireless

Insulation class

II

Compliance

CE, UKCA

IP rating

IP65

IK rating

IK04

EN 1838

EN 1838

Glow wire test

850 °C – 30s

Mounting luminaire

Recessed ceiling

Warranty

5 Years, 10 Years

Emergency duration (h)

3

Battery

LiFePO4 6.4 V 3.2 Ah

Nominal flux (lm)

Optic E 560 – Optic W 580

Polar curve image

YES

Power consumption AC (W)

Max. 11.6

Charging times (h)

24

Mode of operation

Maintained, Non-maintained

Colour temperature (°K)

5000

Service life L80B20

50000

Colour

RAL 9003

Material

PC

Operating temperature (°C)

0 to +45

  • L21026 WAYLUX IP65 RC NRG ZB LDT photometric data (ZIP) - 23.63 KB
  • UKCA Declaration of Conformity NRG ZB L21026 (PDF) - 254.75 KB
  • EG-EU Declaration of Conformity NRG ZB L21026 (PDF) - 298.92 KB
